Stainless Steel Check Valve, 1/2-2 Inch, 150-1500 LB
Key Specifications / Features
Model No.: Hits: 28
Stainless Steel Check Valve Maker: SS Check Valves, 1/2-2 Inch, Class 150-1500 LB, PN16-PN250, API 602, ASME B16.34, ASTM A182, SAF 2205, RF, RTJ, BW, Grooved.
Request a quoteTags
Detail Information
Stainless Steel Check Valve
Med Stainless Steel Check Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or Equivalent, o reduce the flow resistance and pressure drop to the minimum possible extend, which is suitable to be mounted in horizontal position only, lapped and screwed in seat ring ensures tight shut off and long duration service. Valve's disc is perfectly designed, accurately machined and guided for efficient automatic shut off at zero pressure, with a feature of compact structure & Low emission service. In both Swing & Piston Constructions.
Standards Compliance:
Design & Manufactured: API 602 or ASME B16.34.
P.T Ratings: ASME B16.34.
Face to Face Dimensions: ASME B16.10.
Flanged Ends: ASME B16.5.
Butt-weld Ends: ASME B16.25.
Threaded Ends: ASME B1.20.1.
Socket-weld Ends: ASME B16.11.
Valves Marking: MSS SP-25.
Inspect & Tested: API 598.
Structured in Bolted Cover.
Pressure Ratings: Class 150-1500 LB, PN16-PN250.
Ends Connections in Flanged R.F or RTJ, Butt-welded and Grooved.
Size Ranges: 1/2-2 Inch.
Body Materials available in ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L, SS 904L, ASTM A182 F51, SAF 2205 and etc.
Trim Materials available in 13%Cr, ASTM A182 F11, ASTM A182 F22, SS 304, SS 304L, SS 316, SS 316L and other specials.
Full Bore Reduce Ports.
Med Stainless Steel Check Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or Equivalent, o reduce the flow resistance and pressure drop to the minimum possible extend, which is suitable to be mounted in horizontal position only, lapped and screwed in seat ring ensures tight shut off and long duration service. Valve's disc is perfectly designed, accurately machined and guided for efficient automatic shut off at zero pressure, with a feature of compact structure & Low emission service. In both Swing & Piston Constructions.
Standards Compliance:
Design & Manufactured: API 602 or ASME B16.34.
P.T Ratings: ASME B16.34.
Face to Face Dimensions: ASME B16.10.
Flanged Ends: ASME B16.5.
Butt-weld Ends: ASME B16.25.
Threaded Ends: ASME B1.20.1.
Socket-weld Ends: ASME B16.11.
Valves Marking: MSS SP-25.
Inspect & Tested: API 598.
Structured in Bolted Cover.
Pressure Ratings: Class 150-1500 LB, PN16-PN250.
Ends Connections in Flanged R.F or RTJ, Butt-welded and Grooved.
Size Ranges: 1/2-2 Inch.
Body Materials available in ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L, SS 904L, ASTM A182 F51, SAF 2205 and etc.
Trim Materials available in 13%Cr, ASTM A182 F11, ASTM A182 F22, SS 304, SS 304L, SS 316, SS 316L and other specials.
Full Bore Reduce Ports.
