Side Entry Ball Valve, ASTM A350 LF6, 900 LB, 6 IN, API 608
Key Specifications / Features
Model No.: Hits: 11
Side Entry Ball Valve Fabricator: ASTM A350 LF6 Ball Valve, Class 900, 6 Inch, 1/2 - 6 Inch, API 608, BS 5351, Forged Steel Side Entry, RF Flanged End.
Request a quoteTags
Detail Information
Carbon Steel Flanged Ball Valve, Class 900, 6 Inch, BS 5351, Forged Steel Side Entry.
Quick Detail
Type: Flanged End Ball Valve.
Material: ASTM A350 LF6.
Valve Size: 6 Inch.
Applicable Pressure Rating: Class 900 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
Product Range
Material: ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy.
Standards: API 608, BS 5351, ASME B16.34, ASME B16.11, ASME B1.20.1, ASME B16.25.
Valve Size: 1/2 - 6 Inch.
Applicable Pressure Rating: Class 150 LB - 1500 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
STANDARD MATERIALS
Quick Detail
Type: Flanged End Ball Valve.
Material: ASTM A350 LF6.
Valve Size: 6 Inch.
Applicable Pressure Rating: Class 900 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
Product Range
Material: ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy.
Standards: API 608, BS 5351, ASME B16.34, ASME B16.11, ASME B1.20.1, ASME B16.25.
Valve Size: 1/2 - 6 Inch.
Applicable Pressure Rating: Class 150 LB - 1500 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
STANDARD MATERIALS
| PART NAMES | MATERIALS |
| BODY | ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy. |
| BONNET | ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy. |
| SEAT | R-PTFE |
| BALL | ASTM A276 316 |
| Stem | ASTM A276 316 |
| O-RING | NBR |
| BACK SEAT GASKET | PTFE |
| PACKING | GRAPHITE |
| WRENCH | CARBON STEEL |
