Pressure Seal Globe Valve, BS 1873, ASME B16.34, DIN 3202
Key Specifications / Features
Model No.: Hits: 16
Pressure Seal Globe Valve Provider: Pressure Seal Bonnet Globe Valves, BS 1873, ASME B16.34, DIN 3202, 1/2-24 Inch, Class 600-2500 LB, PN100-PN420.
Request a quoteTags
Detail Information
Pressure Seal Globe Valve
Med Pressure Seal Globe Valves are intended for high pressure, high-temperature applications in all types of fluid except where severe coking is a factor. The design and material selections provide excellent service in steam-generation stations, industrial chemical plants and thermal power plants.
Med Pressure Seal Gate Valves provide the most efficient flow passage and sealing features possible, resulting in significant weight savings, easy installation and in-line maintenance.
Supplied with standard features as below
Standards Compliance: Design & Manufactured to BS 1873, ASME B16.34 or DIN 3202
P.T Ratings: ASME B16.34
Face to Face dimensions: ASME B16.10
Flanged Ends: ASME B16.5
Butt-weld Ends: ASME B16.25
Threaded Ends: ASME B1.20.1
Socket-weld Ends: ASME B16.11
Valves Marking: MSS SP-25
Inspect & Tested: API 598
Size Ranges: 1/2-24 Inch.
Pressure Ratings: Class 600-2500 LB, PN100-PN420.
Structures in Pressure Sealed Union Cover.
Ends Connections in Flange, Threaded, Welded Ends and grooved.
Body Materials available in Cast Carbon Steel, Cast Stainless Steel, Cast Duplex Steel, Special Materials etc.
Trim Materials available in 13%Cr, ASTM A182 F11, ASTM A182 F22, SS 304, SS 304L, SS 316, SS 316L and other specials.
Actuations can be equipped with Handwheel, Gear Device, Electric, Pneumatic or Hydraulic Actuators.
Optional Bypass system, Live Loading Packing & O-ring Seal available upon request.
Med Pressure Seal Globe Valves are intended for high pressure, high-temperature applications in all types of fluid except where severe coking is a factor. The design and material selections provide excellent service in steam-generation stations, industrial chemical plants and thermal power plants.
Med Pressure Seal Gate Valves provide the most efficient flow passage and sealing features possible, resulting in significant weight savings, easy installation and in-line maintenance.
Supplied with standard features as below
Standards Compliance: Design & Manufactured to BS 1873, ASME B16.34 or DIN 3202
P.T Ratings: ASME B16.34
Face to Face dimensions: ASME B16.10
Flanged Ends: ASME B16.5
Butt-weld Ends: ASME B16.25
Threaded Ends: ASME B1.20.1
Socket-weld Ends: ASME B16.11
Valves Marking: MSS SP-25
Inspect & Tested: API 598
Size Ranges: 1/2-24 Inch.
Pressure Ratings: Class 600-2500 LB, PN100-PN420.
Structures in Pressure Sealed Union Cover.
Ends Connections in Flange, Threaded, Welded Ends and grooved.
Body Materials available in Cast Carbon Steel, Cast Stainless Steel, Cast Duplex Steel, Special Materials etc.
Trim Materials available in 13%Cr, ASTM A182 F11, ASTM A182 F22, SS 304, SS 304L, SS 316, SS 316L and other specials.
Actuations can be equipped with Handwheel, Gear Device, Electric, Pneumatic or Hydraulic Actuators.
Optional Bypass system, Live Loading Packing & O-ring Seal available upon request.
