Differences between Electric Ball Valves and Electric Butterfly Valves
Electric ball valves are important actuators in industrial automation control systems. Electric butterfly valves belong to a variety of electric valves and electric control valves. The main connection methods of butterfly valves are the flange type and wafer type.
The main sealing forms of butterfly valves include rubber sealing and metal sealing. The butterfly valve controls its opening and closing through a power signal. This product can be used as a shut-off valve, control valve, and check valve for pipeline systems. Equipped with a manual control device, it can be temporarily operated manually without affecting usage in case of power failure. The ball valve is a valve that rotates around the axis of the valve stem based on the movement of the valve disc. The change in the valve seat opening is directly proportional to the valve disc stroke. It is mainly used to cut off or connect the medium in pipelines, and can also be used for fluid regulation and control. It is a pipeline pressure component for industrial automation process control.
The structural characteristics of electric ball valves are as follows.
1. Locking holes are installed in the fully open and fully closed positions of the valve to prevent accidental operation by non-workers.
2. Set steps at the bottom of the valve stem to prevent abnormal internal pressure rise and detachment from the valve stem.
3. Install a fire-resistant sealing ring between the ball and the valve seat, which still has a sealing effect after the valve seat is burned out.
4. Quick switch, flexible opening and closing and long service life. It is safe and reliable. 5. Pneumatic ball valves can be remotely and centrally controlled, and can meet the needs of computer programming.
The working principle of clamp-type electric butterfly valves (D971X, D971F).
The working power supply usually includes AC220V, AC380V, etc.
Input signal: weak current signals such as 4-20mA0-10v. After the adjustment, the electric actuator and valve stem are connected and debugged. Use electrical energy as the driving force to drive the hard-sealed butterfly valve plate and perform a partial rotation motion of 0 to 90 degrees. Receive 4-20mA signals from industrial automation control systems to control valve opening, thereby achieving adjustment and control of different process parameters such as flow, temperature, and pressure.
The application field of electric butterfly valves: It is widely used in industrial process automatic control systems in industries such as food, environmental protection, light industry, petroleum, chemical industry, water treatment, municipal engineering, paper-making, power, water treatment, etc.
Butterfly valves are suitable for the HVAC and refrigeration industries, as well as for industrial, general service, and water treatment applications.
The advantages of electric butterfly valves.
1. The butterfly valve is easy to open and close quickly. It's labor-saving and has low fluid resistance, which can be operated frequently.
2. The Butterfly valve has a simple structure, small volume, and light weight.
3. Butterfly valves can transport mud and accumulate less liquid at the pipeline mouth.
4. Butterfly valves can achieve good sealing under low pressure.
5. The butterfly valve has good regulating performance.
Disadvantages of electric butterfly valves:
1. The operating pressure and temperature range are small.
2. Poor sealing performance.
Installation and maintenance of electric butterfly valves:
1. During installation, the valve disc should be stopped in the closed position.
2. The opening position should be determined according to the rotation angle of the butterfly plate. 3. Butterfly valves with bypass valves should be opened before opening.
4. According to the manufacturer's instructions
5. The overall paint baking can effectively prevent rust and can be used in different media as long as the sealing material of the valve seat is replaced.
6. This valve has a bidirectional sealing function, and is not controlled by the flow direction of the medium or affected by spatial location during installation. It can be installed in any direction.
7. It has a small size, light weight, reliable performance, simple matching, and large flow capacity, which is especially suitable for medium cleaning liquids and gases.
