Electric Operated Ball Valve, A105, 24IN, CL150, ASME B16.34
Key Specifications / Features
Model No.: Hits: 16
Electric Operated Ball Valve Manufacturer: Carbon Steel ASTM A105 Ball Valves, 24 Inch, Class 150 LB, ASME B16.34, API 6D, Electric Operation, RF Ends.
Request a quoteTags
Detail Information
24 Inch Ball Valve, ASTM A105, ASME B16.34, Class 150, RF End, API 6D Standard, Electric Operation.
Valve Description
Design Standard: API 6D, ASME B16.34.
Body Material: ASTM A105.
Nominal Diameter: 24 Inch.
Pressure: Class 600 LB.
End Connection: RF.
Face to Face: ASME B16.10.
Working Temperature: -29℃ - +200℃.
Mode of Operation: Electric.
Test and Inspection: API 598.
Product Range
Body Material: Low-Temperature Carbon Steel.
Normal Diameter: 2-60 Inch (DN50-DN1500).
End Connection: BW, Flanged.
Pressure Range: Class 150-2500 LB (PN16-PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro-Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃ - +200℃.
Valve Description
Design Standard: API 6D, ASME B16.34.
Body Material: ASTM A105.
Nominal Diameter: 24 Inch.
Pressure: Class 600 LB.
End Connection: RF.
Face to Face: ASME B16.10.
Working Temperature: -29℃ - +200℃.
Mode of Operation: Electric.
Test and Inspection: API 598.
Product Range
Body Material: Low-Temperature Carbon Steel.
Normal Diameter: 2-60 Inch (DN50-DN1500).
End Connection: BW, Flanged.
Pressure Range: Class 150-2500 LB (PN16-PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro-Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃ - +200℃.
