API 608 Ball Valve, ASTM A105N, 150 LB, 2 Inch, Flanged End
Key Specifications / Features
Model No.: Hits: 15
API 608 Ball Valve Manufacturer: Forged Steel Side Entry Ball Valves, Carbon Steel, ASTM A105N, Class 150 LB, 2 Inch, API 608, Flanged End.
Request a quoteTags
Detail Information
Carbon Steel Flanged Ball Valve, A105N, Class 150, 2 Inch, API 608, Forged Steel Side Entry.
Quick Detail
Type: Flanged End Ball Valve.
Design Standard: API 608.
Material: ASTM A105N.
Valve Size: 2 Inch.
Applicable Pressure Rating: Class 150 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
Product Range
Material: ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy.
Standards: API 608, BS 5351, ASME B16.34, ASME B16.11, ASME B1.20.1, ASME B16.25.
Valve Size: 1/2 - 4 Inch.
Applicable Pressure Rating: Class 150 LB - 1500 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
FORGED STEEL SIDE ENTRY BALL VALVE - Free Floating Ball ( 2 Piece )
STANDARD MATERIALS
Quick Detail
Type: Flanged End Ball Valve.
Design Standard: API 608.
Material: ASTM A105N.
Valve Size: 2 Inch.
Applicable Pressure Rating: Class 150 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
Product Range
Material: ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy.
Standards: API 608, BS 5351, ASME B16.34, ASME B16.11, ASME B1.20.1, ASME B16.25.
Valve Size: 1/2 - 4 Inch.
Applicable Pressure Rating: Class 150 LB - 1500 LB.
Temperature Rating: Up to 250℃.
Molding Style: Forging.
FORGED STEEL SIDE ENTRY BALL VALVE - Free Floating Ball ( 2 Piece )
STANDARD MATERIALS
| PART NAMES | MATERIALS |
| BODY | ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy. |
| BONNET | ASTM A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy. |
| SEAT | R-PTFE |
| BALL | ASTM A276 316 |
| Stem | ASTM A276 316 |
| O-RING | NBR |
| BACK SEAT GASKET | PTFE |
| PACKING | GRAPHITE |
| WRENCH | CARBON STEEL |
